| Technical Data | ||
| Maximal Force | +/- 20 MN | |
|
Distance between the Compression Platens |
Maximum | 10.000 mm |
| Minimum | 500 mm | |
| Size of Compression Platens | 2.500 x 2.500 mm2 | |
| Size of Tension Platens | 1.500 x 1.500 mm2 | |
| Clear Distance between the column | 2.130 x 2.000 mm2 | |
| Max. Stroke of Actuator | 500 mm | |
| Pulsating Load for Compression Test | 0 - 20 MN | |
| Pulsating Load for Tension Test | 0 - 18 MN | |
| Alternating Tension/Compression Test | ± 8 MN | |
| Servo Valve Rated Flow | 1.000 l/min | |
| Control Unit | Instron Labtronic 8800 | |
